Mipro ACT-2412/ACT-24TC Full-Rack dual-channel digital receiver (2.4GHz) with 2 body pack transmitters and 1 charger MP-80
Features:
ACT-2412 Dual-Channel Digital Receiver
- Dual-Channel Digital Receiver
- 2.4GHz-ISM band stable digital FSK modulation circuitry
- Chassis EIA Standard 19" 1U
- Display Graphic OLED
- Frequency Range ISM 2,400 – 2,4835 MHz
- Receiving Mode Dual-tuner Digital Diversity
- Audio Sampling 24-bit / 44.1 kHz
- Sensitivity -95 dBm
- S/N Ratio > 115 dB(A)
- T.H.D. 0.1 % @ 1 kHz
- Audio Frequency Response 20 Hz – 20 kHz (-2 dB)
ACT-24TC Rechargeable Body-Pack Transmitter
- Rechargeable Body-Pack Transmitter
- Miniature, sturdy plastic compact design
- Miniature, sturdy plastic compact design
- 3 LEDs indicate battery status and turn to red to indicate low battery
- Unique battery cover design provides easy access to operational controls and protects against accidental change of settings
- LED in the mute/AF button is lit or off to indicate AF status
- One-touch ACT syncs the transmitter and receiver frequency automatically
ACT-2412 Data Sheet
ACT-24TC Data Sheet
